HASTELLOY C-276（UNSN10276） PIPE / TUBE
Nickel-Chromium-Molybdenum-Tungsten Alloy for Severe Corrosive Environments
HASTELLOY C-276 pipe and tube are used in corrosive fluid handling, chemical processing, and heat exchange services where resistance to pitting, crevice corrosion, and chloride stress corrosion cracking is critical. The alloy also performs well in wet chlorine, hypochlorite, and chlorine dioxide environments.
As a professional Chinese nickel-based alloy manufacturer, we supply HASTELLOY C-276 pipes and tubes with stable chemistry, consistent mechanical properties, and flexible dimensional customization for global industrial users.
Typical supply range (custom sizes and tolerances available upon request):
Item | Range / Options | Notes |
Outside diameter (OD) | 6 – 610 mm | NPS sizes available; specify OD tolerance if critical. |
Wall thickness (WT) | 0.5 – 30 mm | Sch schedules by request; define minimum/maximum tolerance. |
Length | Up to 12 m | Fixed length or random length; cut-to-length by agreement. |
Type / process | Seamless / Welded | Seamless for critical service; welded available by size. |
End preparation | Plain end (PE) / Bevel end (BE) | End caps and protection available. |
NDT / testing | UT / ET / Hydro (as required) | Define inspection level for projects and code compliance. |
Delivery condition | Solution annealed (standard) | Pickled/bright depending on surface requirement. |
Dimension definition: OD × WT × LENGTH.
• Excellent resistance to pitting and crevice corrosion in chloride media
• Outstanding resistance to chloride stress corrosion cracking (SCC)
• Strong resistance to oxidizing and reducing acids in mixed process media
• Withstands wet chlorine gas, hypochlorite, and chlorine dioxide solutions
• Extremely low carbon and silicon for improved as-welded corrosion performance
• Good fabrication and welding performance for CPI equipment
Element | Ni | Cr | Mo | Fe | W | Mn | Si | C |
HASTELLOY C-276 | Balance | 14.5–16.5 | 15.0–17.0 | 4.0–7.0 | 3.0–4.5 | ≤1.0 | ≤0.08 | ≤0.01 |
Extremely low carbon and silicon help maintain corrosion resistance in as-welded structures.
Property | Value |
Tensile Strength (Rm) | ≥ 690 MPa |
Yield Strength (Rp0.2) | ≥ 283 MPa |
Elongation | ≥ 40 % |
Hardness | ≤ 90 HRB |
Mechanical properties may vary slightly with product form and heat treatment condition.
Standard System | Specification |
ASTM / ASME | ASTM B622 / ASME SB-622 (Seamless); ASTM B619 / SB-619 (Welded Pipe); ASTM B626 / SB-626 (Welded Tube) |
EN | EN 10204 |
UNS | N10276 |
DIN | 2.4819 |
JIS | NW 0276 |
Item | Range |
OD | 6 – 610 mm |
WT | 0.5 – 30 mm |
Length | Up to 12 m |
Type | Seamless / Welded |
End | PE / BE |
Custom sizes, tight tolerances, and cut-to-length service are available upon request.
• Solution Annealed
• Pickled / Bright Annealed (as required)
• Chemical processing reactors, columns, and heat exchangers
• Flue gas desulfurization (FGD) scrubbers, ducting, and absorbers
• Pulp & paper bleach plant and chemical handling equipment
• Chlorination systems and hypochlorite service equipment
• Waste incineration / pollution control systems
• Oil & gas sour service and corrosion-resistant components
• Seawater / brine handling and marine environments
HASTELLOY C-276 can be fabricated and welded using standard nickel-alloy practices.
Common welding methods include:
• GTAW (TIG)
• GMAW (MIG)
• SMAW
Matching filler metals such as ERNiCrMo-4 are typically recommended.
• EN 10204 3.1 Material Test Certificate
• Chemical composition analysis
• Mechanical testing (tensile, hardness)
• PMI / XRF testing available
• Dimensional inspection
• Third-party inspection on request (BV, SGS, TUV, DNV)
• PVC protective film on surface (where applicable)
• Wooden pallets or export-grade crates
• Seaworthy packaging for long-distance shipment
• Global delivery by sea, air, or multimodal transport
• Professional nickel-based alloy manufacturer in China
• Stable raw material sourcing and melting control
• Wide stock and fast production cycle
• Competitive pricing for global projects
• Experience with international EPC, OEM, and distributors
For quotation or technical consultation, please provide:
• Required grade (HASTELLOY C-276)
• OD × WT × Length
• Quantity
• Surface finish / delivery condition
• Application environment
Our technical team will respond with datasheets, pricing, and delivery schedule promptly.
